The Starter Kit | Off-Grid Solar System

Gel:
Solar Panel Array Size : 880 W
Generation in 3 Peak Sun Hours : 2640 Wh
Number of MPPT Trackers: 1

Total Storage : 4800 Wh
Usable Storage : 2400 Wh
Nominal Voltage : 24 V

Inverter Continuous Rating : 2000 W
Inverter Rating 30min : 2000 W
Inverter Peak Rating : 4000 W

Lithium:
Solar Panel Array Size : 880 W
Generation in 3 Peak Sun Hours : 2640 Wh
Number of MPPT Trackers: 1

Total Storage : 2560 Wh
Usable Storage : 2048 Wh
Nominal Voltage : 25.6 V

Inverter Continuous Rating : 2000 W
Inverter Rating 30min : 2000 W
Inverter Peak Rating : 4000 W

Mobile:
Solar Panel Array Size : 880 W
Generation in 3 Peak Sun Hours : 2640 Wh
Number of MPPT Trackers: 1

Total Storage : 2560 Wh
Usable Storage : 2048 Wh
Nominal Voltage : 24 V

Inverter Continuous Rating : 2000 W
Inverter Rating 30min : 2500 W
Inverter Peak Rating : 4500 W

Starter Kit Gel components:

• 2× Monocrystalline Solar Panel
• 2× 12V 200Ah Gel Lead Acid Deep Cycle Batteries
• 1× 30A Solar Charge Controller
• 1× 2000W 24V Inverter
• 2× Z-Bracket Solar Mounts
• 1× 10m Solar Cable Pair
• 1× 15A MCB
• 1× 32A MCB
• 1× 125A MCB
• 1× MCB Enclosure
• 1× 3m 16mm² Precrimped Cable Pair
• 1× 3m 25mm² Precrimped Cable Pair
• 1× 30cm 50mm² Battery Series Cable

Starter Kit Lithium components:

• 2× Monocrystalline Solar Panel
• 1× 25.6V 2.56kWh LiFeP04 Lithium Battery
• 1× 30A Solar Charge Controller
• 1× 2000W 24V Inverter
• 2× Z-Bracket Solar Mounts
• 1× 10m Solar Cable Pair
• 1× 15A MCB
• 1× 32A MCB
• 1× 125A MCB
• 1× MCB Enclosure
• 1× 3m 16mm² Precrimped Cable Pair
• 1× 3m 25mm² Precrimped Cable Pair

Starter Kit Mobile components:

• 2× Monocrystalline Solar Panel
• 1× Starter Kit Mobile Hybrid Inverter
• 2× Z-Bracket Solar Mounts
• 1× 10m Solar Cable Pair

Gel Battery Upgrades:
Up to 6 Gel batteries total can be used on this kit.
Battery upgrades should be done within 6 months of purchasing to avoid significant age differences. Warranties are affected if upgrading outside this range.

Lithium Battery Upgrades:
Up to 4 Lithium batteries total can be installed on this kit.
Battery upgrades should be done within 6 months of purchasing to avoid significant age differences. Warranties are affected if upgrading outside this range.

Solar Panel Upgrades:
To add panels separate charge controllers are required as well as panels. There is no hard limit on this type of upgrade.

Starter Mobile:
An expander battery can be added to this kit but the panels cannot be upgraded.

For all options please get in touch with the team for advice and a discount on your upgrade parts.

TW Tier 1 Solar panel:
25 year material / 30 year performance warranty

Epever LiFePo4 Lithium Battery: Standard 3 yr warranty (No Depth of Discharge requirement)

Gridfree 12V200Ah Lead Acid GEL battery:
Standard 3 yr limited warranty on 50% Depth of Discharge

EPEVER IPT Series Inverter:
Standard 2 yr warranty

EPEVER Tracer Series MPPT Charge controller:
Standard 2 yr warranty

Download Installation guide - Starter Kit GEL

Download Installation guide - Starter Kit Lithium
