Tui Solar Nest | All-In-One Cabinet Solution

Tui Solar Nest | All-In-One Cabinet Solution

Name: Tui Solar Nest | All-In-One Cabinet Solution
Brand: Gridfree
SKU: SOLARNEST-TUI-10
Price: 22000.0 NZD
Availability: InStock

$22,000.00

Battery Upgrade:

Variant

GridFree's Tui Solar Nest Cabinet is an integrated, all-in-one system for off-grid applications - a plug'n'play solution. This pre-built IP54-rated cabinet is the ideal solution for baches, tiny homes, and lifestyle properties that have no access to grid power, as they have an easier, faster, and cheaper installation than our DIY kits, are easy to relocate, and are more resilient to environmental conditions. Powered by the TBB Renewable Raython M2 series cabinet.

These standalone systems are factory assembled and tested, and shipped as a complete off-grid solar system. The All-in-One solution incorporates an inverter charger with an MPPT solar charge controller, lithium battery modules, E4 monitoring and AC/DC/PV power distribution in one box. Electrician required for install.

Need more power? Contact us for larger Solar Nest systems.

Kit Contents, Specs, and Manuals can all be found below.

Scroll to mounts info

Finance available for kits. Click here to learn more.

Want to chat? Call 09 218 5533, or email info@gridfree.store.

Find shipping rates here, or at the bottom of the page.

Information about upgrades, specs, and installation can be found lower down the page.

Installation: The solar panels and their cables are the only parts in these kits that are okay outside. The charge controller, inverter, and hybrid inverter are not IP rated and should be kept away from moisture including condensation.

What are peak sun hours? Read this article.

How do you know how much power you need? Read this article.

What not to run on solar? Read this article.

With 12 solar panels and 10kWh of batteries, the Tui provides enough power to accommodate a lot of home comforts. It offers stronger surge capability and powerful overload capability to power heavier loads like occasional power tool or aircon use, or simply running more things at once. The automatic start/stop function for generator input ensures continuous power supply, and the power assistance functionality enables limited AC source to power heavy loads with the assist of battery power. Plus, the advanced Web & App interfaces allow for system remote monitoring and control, with an in-built E4 monitor for local monitoring and control.

What can the Tui Solar Nest run?

Below is an example of one day's total power usage, if you're getting at least 3 sun hours - this is ~14,400Wh of energy per day and can be expected for >80% of the year. (Learn more.) These items are a guide to what you might run over one day, and they can be swapped out to suit your needs within the generation estimate. (Read more.) We highly recommend having a back-up generator with these kits if you won't be able to conserve power during low-sun periods. (Need a jargon breakdown?) The SolarNest kits offer a higher surge capability than our other kits, allowing you to run more things at once, or occasionally run high-load items such as power tools or aircon.

Efficient Fridge/Freezer

24 hours a day (1000wh)

375L Chest Freezer

24 hours a day (460wh)

1800W Kettle

10 minutes (300wh)

2000W 4 Slice Toaster

12 minutes (200wh)

1800W Dishwasher

1 hour a day (1800wh)

500W Washing Machine

4x a week avg (250wh)

1800W Corded Tools

30 minutes a day (900wh)

2000W Airfryer

30 mins a day (1000wh)

Starlink Satellite

24 hours a day (1000wh)

1500W Hairdryer

15 minutes (375wh)

240W Lighting

8 hours a day (1920wh)

2000W Coffee Maker

10 minutes (300wh)

2000W Microwave

20 minutes (600wh)

25W Phone Charger

12 hours a day (300wh)

60W Laptop

12 hours a day (720 wh)

50W Fan

8 hours a day (400wh)

600W Water Pump

2 hours a day (1200wh)

20W Wireless Router

24 hours a day (480wh)

100W Television

6 hours a day (600wh)

200W Cordless Vacuum

30 minutes (100wh)

Not sure how much power you need? Read this article to learn how to calculate your needs.

This example doesn't account for days when you may have to cut back on power use (or supplement with a generator) due to several days of poor weather preventing your batteries from fully recharging each day. Learn more here. Our kits should not be used for vital or life-supporting systems, and we recommend finding alternative solutions for Water/Space Heating, Cooking, or EV charging to maximise your budget - Why?

Need More Power?

We have larger SolarNest Cabinet Systems available upon request. Please get in touch to discuss you needs and we can find the right solution.

Contact Us to discuss larger solarnest kits

Includes everything you need to get up and running.

<p>This kit comes with all the components and connections pre-installed in one cabinet, plus the panels, cables, and mounting hardware, to make for a quick, easy, and more affordable installation.</p><ul><li><a href="https://gridfree.store/products/tw-solar-400w-perc-mono-half-cell-solar-panel-full-black-module">12x 400W TW PERC Mono Half-Cell Solar Panels</a></li><li>TBB Renewable Raython M2 IP54-rated cabinet preinstalled with:<ul><li>Kinergier Pro 5kVA Inverter Charger</li><li>Solar Mate 100A Charge Controller</li><li>E4 Monitor</li><li>Cables and Circuit Breakers</li></ul></li><li>2x 5kWh ES100 Lithium Batteries </li><li>PV Cable</li><li>PV Combiner Box</li><li>Your choice of Chiko roof mount (upgradable to tilt/ground)</li></ul><p>With this kit you are able to add 2 additional batteries to create a 20kWh bank, and it's best to do so within 3-6 months of purchase to ensure longevity.</p>

Tui Solar Nest Specifications

Total Weight: 700 kg

Solar Panels: 20kg each, Lithium Batteries: 40kg each

Dimensions

Panels: 1100x1750x30mm, Batteries: 650x260x170mm

Daily Expected Output

Array: 12 x 400W, Winter: 14.4 kWh, Summer: 24 kWh

Inverter Output

Cont. Output power at 25°: 4000W, Peak power (30 min): 5000W, Peak power (10 Sec): 10000W, Surge: 300%, Maximum Efficiency: 96%, Zero Load Power: 19W

Storage Capacity

Lithium: 10.12kwh (8.096kWh Usable)

Charge Controller

Current: 100A, Maximum PV power: 7500W, PV open circuit voltage: 250V, Maximum PV short circuit current: 80A, MPPT voltage range: 65 ~ 245V, MPPT Charge maximum efficiency: 98% MPPT efficiency: 99.9%

Universal

The Universal Roof Mount allows you to mount your panels flat on any type of roof along a pair of rails. The rails are attached to the roof with L-shaped brackets, and the panels are clamped to the rails, making it much easier to mount four or more panels on your roof.

Corrugated

The Corrugated Iron Roof mount performs similarly to the universal roof mount, but it is a rail-free option that sits in the grooves of corrugated iron. The mounts are secured to the roof and then the panels are clamped onto them directly instead of rails.

Ground

The Ground mount allows you to mount your panels on the ground along a pair of rails attached to a triangular frame, and the panels are clamped to the rails. The frame is mounted on something secured in the ground, and the angle can only be adjusted during the install.

Tilt

The Tilt mount allows you to mount your panels on a flat/low pitch roof at an angle to maximise solar energy, adjustable by up to 15 degrees after the initial install. The rails are attached to a triangular frame mounted to the roof, and the panels are clamped to the rails.
