TBB Power - Kinergier Pro 8000W Inverter Charger

Regular price $3,850.00 NZD Sale price $3,850.00 NZD
Tax included.
In stock

Description

The Kinergier Pro from TBB Power is an advanced inverter charger that combines an inverter, battery charger, and transfer switch in a compact package, with the capability to expand system capacity through parallel and three-phase operation for up to nine units. Designed for various off-grid systems, including DC Coupled PV, AC Coupled PV, or a combination of both, it maximizes the use of solar energy.

With 0ms UPS transfer time and high surge capability, it efficiently powers mission-critical loads and high-demand appliances like air conditioners, pumps, and freezers. Its power assist and control functions ensure compatibility with most generators, automatically adjusting charging currents to prevent generator overload and discharging the battery during peak power demands to supplement generator output.


Fully Compatible with TBB Power / TBB Solar range of Lithium batteries (ES100 II)

Battery Voltage: 48VDC

Battery Type: Lithium/Lead-Acid

INVERTER OUTPUT

Peak Power (30min): 8000W

Parallel Capability: YES

Peak Power(10 sec): 16000W

Efficiency (Peak): 96%

Waveform: Pure Sine Wave

Transfer Time: 0ms (<15ms in Weak AC source mode)

AC Input Voltage: 230VAC

Max AC Charge current: 110A

Physical

Protection Degree: IP20

Dimension (W/H/D): 530/285/185mm

Net Weight: 40kg

Operating Environment

Low humidity areas: <95% (Non-Condensing)

Altitude: <2000m

Operating Temperature: -20°C - 60°C

Warranty

2 Years

CEC-Listed

No downloads
