TBB Power SolarMate 600V 120A MPPT Charge Controller

TBB Power SolarMate 600V 120A MPPT Charge Controller

$1,600.00

The SP600-120 is TBB Solar's latest solar charge controller with up to 600VDC PV open circuit voltage and 120A charge current, used for charging 48VDC battery banks. It is an ideal solution for larger on-grid and off-grid solar systems which require higher battery charging power. Featuring high open-circuit voltage and a wide 80-525 V MPPT tracking, it can save your configuration and installation cost of the combiner box, thus greatly minimizes the system cost. With two independent tracking trackers, you can optimize your solar panel installation for maximum use of solar energy.

View Features/Specs/Downloads
Quantity:

Powering the Solar Nest Series

This charge controller is included in our Tui Solar Nest, an integrated, all-in-one system for off-grid applications - a plug'n'play solution. This pre-built IP54-rated cabinet is the ideal solution for baches, tiny homes, and lifestyle properties that have no access to grid power, as they have an easier, faster, and cheaper installation than our DIY kits, are easy to relocate, and are more resilient to environmental conditions. Powered by the TBB Renewable. Learn more here.

<p><strong>Charger</strong></p>
<ul>
<li><strong>Battery Voltage:</strong> 48V</li>
<li><strong>Maximum Charge Current:</strong> 120A</li>
<li><strong>Maximum Charge Power:</strong> 7000W @ 57.6V total, 5000W @ 57.6V per tracker</li>
<li><strong>Charge Voltage 'Absorption':</strong> Default: 57.6V</li>
<li><strong>Charge Voltage 'Float':</strong> Default: 54.0V</li>
<li><strong>Charger Voltage Range:</strong> 40-60V</li>
<li><strong>Battery Types:</strong> AGM/GEL/OPzV/Lead-Carbon/Lithium</li>
<li><strong>Battery Temperature Sensor:</strong> Included</li>
<li><strong>Maximum Efficiency:</strong> 97%</li>
<li><strong>Self-Consumption:</strong> 80mA @ 48V</li>
</ul>

<p><strong>Solar</strong></p>
<ul>
<li><strong>Maximum PV Open Circuit Voltage:</strong> 600V</li>
<li><strong>Start-up Voltage:</strong> 120V</li>
<li><strong>PV Operating Voltage Range:</strong> 120-525V</li>
<li><strong>MPPT Voltage Range:</strong> 80-525V</li>
<li><strong>Number of MPPT Trackers:</strong> 2</li>
<li><strong>Maximum PV Input Current per Tracker:</strong> 18A + 18A</li>
<li><strong>Maximum PV Short Circuit Current per Tracker:</strong> 20A + 20A</li>
<li><strong>Allowable Maximum PV Panel Power per Tracker:</strong> 8000W + 8000W</li>
<li><strong>MPPT Efficiency:</strong> &gt;99.9%</li>
<li><strong>PV Array Insulation Resistance Detection (Earth Fault Detection):</strong> Integrated</li>
</ul>

<p><strong>General Data</strong></p>
<ul>
<li><strong>Surge Protection:</strong> Yes</li>
<li><strong>Protection:</strong> a) Battery voltage too high; b) Battery voltage too low; c) Temperature too high; d) PV reverse polarity</li>
<li><strong>Dry In Port:</strong> 1</li>
<li><strong>Programmable Relay:</strong> 1 x (28Vdc/4A or 250Vac/2A)</li>
<li><strong>General Purpose Communication Port:</strong> RS485</li>
<li><strong>Relative Humidity in Operation:</strong> 95% without condensation</li>
</ul>

<p><strong>Mechanical Data</strong></p>
<ul>
<li><strong>Dimensions:</strong> 484 x 280 x 108 mm</li>
<li><strong>Net Weight:</strong> 7.8 kg</li>
<li><strong>Protection Index:</strong> IP21</li>
<li><strong>Warranty:</strong> 4 yrs + 1 yr (With TBB NOVA Cloud connection)</li>
</ul>
